  • Cable Copper Conductor PVC Flexible Power Cable

    Brand :CTCW

    Product origin :Shanghai, China

    Delivery time :Quantity(Meters) 1 - 20000 20001 - 50000 >50000 Est. Time(days) 5 10 To be negotiated

    Supply capacity :2000000 meters per day

    Flexible Power Cable is applied to transmit and distribute power in power transmission and distribution system. It is widely adopted in the fields including power, construction, mines, metallurgy, petrochemical industry and communication in complete replace of oil immersed paper insulated power cable and in partial re-place of PVC insulated power cable.

    INTRODUCTION

    Description:

  • Reference standard:UL Subject62, UL758 UL1581

  • PVC insulation

  • Passes UL VW-1,cUL FT1 flame test and complies with RoHS

  • Insulation color:Black, red, pink, yellow or negotiable.

    Product parameters:

    NISPT-1

  • Rated temperature:105℃

  • Rated voltage:300V

  • Solid or stranded,tinned or bare copper conductor 20-18AWG

  • SURFACE MARKING:(UL) E342957 STYLE NISPT-1 ( )AWG VW-1 105℃ 300V  SHANG HAI CHAO TONG…… C(UL)  STYLE NISPT-1()AWG 105℃ 300V  FT2 -F-

    NISPT-2

  • Rated temperature:105℃

  • Rated voltage:300V

  • Solid or stranded,tinned or bare copper conductor16-18AWG

  • SURFACE MARKING:(UL) E342957 STYLE NISPT-2 ( )AWG VW-1 105℃ 300V  SHANG HAI CHAO TONG…… C(UL)  STYLE NISPT-2 (  )AWG 105℃ 300V  FT2 -F-

    SJT, SJTW and SJTOW



  • Rated temperature:60℃,105℃

  • Rated voltage:300V

  • Solid or stranded,tinned or bare copper conductor18-12AWG

  • SURFACE MARKING:(UL) E342957 STYLE SJT(0W) ( )AWG VW-1 105℃ 300V  SHANG HAI CHAO TONG…… C(UL)  STYLE SJT(OW)()AWG 105℃ 300V  FT2 -F-

    Noted:Core No. and specification are not limited to the above regulation,they could be customized.
